PARTE: 2AM-U-300 - ARMADORA DE MARCOS - SEMIAUTOMATICA
NUEVA CON GARANTIA
The U-300 is a bench-top, frame joining machine and the most popular model of custom frame shops. It is compact, well constructed, and built for many years of trouble free operation. The design of the U-300 allows the operator to set the front and back measuring stops for V-Nail insertion. The frame is then moved across the nail head and V-Nails are driven or stacked anywhere along the frame joint. The V-Nail insertion is actuated through the use of a pneumatic pedal.
Unique Performance Features
- Features pneumatic loader to eliminate nail jams
- “Soft Clamping” pneumatic feature for damage free joints
- Quick-change, magnetic pad hold down feature fitting most moulding profiles
- Small table-top footprint needed – 12” (305mm) wide x 19” (483mm) length x 14” (356mm) high
- Operates only with pneumatic air, no electrical hook-up needed
- Dual function foot pedal for separate control of mould clamping and V-Nail insertion
- Designed with a unique, trouble free piston V-Nail driver block-blade system for years of dependable single and multi-stacking operations
Frame Joining Capabilities
Moulding Width (min to max): ¼” up to 3 3/4” (6-60 mm)
Moulding Height (min to max): ¼” up to 3 ¼” (6-80 mm)
Max Distance Between V-Nails (stroke): 3 1/4” (80 mm)
Pre-set V-Nail Position Stops: Multiple
V-Nail Sizes: 5, 7,10,12,15 mm (SW-HW-HDF)
V-Nail Channel Capacity: 220 V-Nails/channel
U-300 Purchase Package
(1) 7mm Nail Head
(1) 10mm Nail Head
(1) 12mm Nail Head
(1) Single Vertical Positive Placement Clamp
(1) Magnetic Base of Clamp Assembly
(1) Blue Rubber Pads (SW)
(1) Yellow Rubber Pads (MW)
(1) Black Rubber Pads (HW)
(1) Round Pressure Pad (Felt)
(1) 4mm Allen Wrench
(1) 5mm Allen Wrench
(1) Front Horizontal Clamp
(1) Machine manual
Machine Dimensions & Weight
Width 300mm (11 ¾")
Length 485mm (19")
Height 456mm (18")
Weight 32kg. (70lbs.)
Power Requirements
Compressed Air 4NI at 5 Bar
Options
Floor Stand for U‐300
Extension Wing Kit for U‐300
Support Table ‐Bracket Kit (includes brackets, washers, M8 bolts, screws)
Support Table, Wood ‐(VN4 (Brackets not included ‐See 04‐046)
